Wear resistant ceramic characteristics and technical indexes
1, the wear-resisting ceramics definition and performance characteristics
The definition of wear-resisting ceramics:
Wear-resisting ceramics is AL2O3 as the main raw material, with rare metal oxide as the flux, through one thousand seven hundred baidu high temperature roasting of special alumina ceramic, with special rubber and high intensity of a combination of organic/inorganic adhesive products.
Wear resisting ceramics performance characteristics:
A high hardness
B, excellent wear resistance
C light weight (only half as much as that of the steel can greatly reduce equipment load)
D good adhesion strong, heat-resisting performance (wear-resisting ceramics piece of heat-resisting strong glue to stick on the inner wall of the equipment)
E Wide range of application
Thermal power, steel, metallurgy, machinery, coal, mining, chemical, cement, port terminals and other enterprises of coal transporting system, pulverizing system, ash discharge and dust removal system, etc
All wear large mechanical equipment, can choose according to different requirements of different types of products.
Wear resistant ceramic main technical indicators
Performance conforms to Q/OKVL001-2003 technical standards
Wear-resistant ceramic main technical indicators:
Project indicators
Alumina content of 95% or higher
Acuity 3.5 g/cm3 density
Rockwell hardness acuity 80 HRA
Or higher compressive strength of 850 Mpa
Fracture toughness K Ι acuity 4.8 MPa, m1/2 C
Bending strength p 290 mpa
Coefficient of thermal conductivity of 20 w/m.K
Coefficient of thermal expansion: 7.2 x 10-6 m/m.K
Type adhesive and impact resistant wear resistant ceramic plate with a rubber key performance indicators:
The project name
Breaking strength (Mpa) 12 or more
Pull-apart extension (%) of 250 or higher
Shaw hardness (55-65 degrees)
Pull a permanent deformation (%) 24 or less
Rubber and ceramic bonding strength (Mpa) (shear stress) of 3.0 or higher
The heat resistance of 100 ℃ or less
Rubber aging age 15 years or more
Type heat resistant adhesive wear resistant ceramic plate with a rubber key performance indicators:
The project name
Breaking strength (Mpa) of 7.5 or higher
Pull-apart extension (%) of 300 or higher
Shaw hardness (c) 48-58
Pull a permanent deformation (%) 16 or less
Rubber and ceramic bonding strength (Mpa) (shear stress) of 3.0 or higher
The heat resistance of 250 ℃ or less
Rubber aging age 15 years or more
Hardy type adhesive wear resistant ceramic plate with a rubber key performance indicators:
The project name
Breaking strength (Mpa) 12 or more
Pull-apart extension (%) of 350 or higher
Shaw hardness (c) 48-58
Pull a permanent deformation (%) 24 or less
Rubber and ceramic bonding strength (Mpa) (shear stress) of 3.0 or higher
Heat resistance - 50 ℃ or higher
Rubber aging age 15 years or more
