Product Name:SIC Silicon Carbide Ceramics
- Product Category:
- Product Details:
- E-Mail:
Chemshun Ceramics SIC Classification :
Chemshun Ceramics Company can supply industrial silicon carbide products, no matter pressureless sintering ceramics (SSIC) or reaction sintering ceramics (SISIC). SSIC and SISIC is difference in firing process. So pressureless sintering ceramics have different technical parameters & product performance with reaction sintering ceramics.
Silicon Carbide Introduction :
Silicon Carbide was originally produced by a high temperature electro-chemical reaction of sand and carbon. Silicon carbide is an excellent abrasive and made into grinding wheels and other abrasive products. Today the material has been developed into a high quality technical grade ceramic with very good mechanical properties. It is used in abrasives, refractories, ceramics, and a large number of high-performance applications. Silicon Carbide can also be made an electrical conductor and has applications in resistance heating, flame ignite and electronic components.
Material Properties :
Properties | Units | RSiC | SiSiC | SSiC |
Bulk denstity SiC | Vo1% | ≥99 | ≥85 | ≥99
|
Bulk density | g/cm3 | 2.60~2.72 | 3.01 | 3.10-3.15 |
Apparent porosity | % | 15 | <0.1 | <0.2 |
Modulus of rupture at 20℃ | Mpa | 80~90 | 250 | 400 |
Modulus of rupture at 1200℃ | Mpa | 90~100 | 280 | 650 |
Modulus of elasticity at 20℃ | Gpa | - | 330 | 410 |
Thermal Conductivity at 1200℃ | w.m-1.k-1 | 35.0 | 45 | 55 |
Thermal expansion at 1200℃ | a×10-6/℃ | 4.60 | 4.5 | 4.0 |
Thermal shock resistance at 1200℃ | Very good | Very good | Very good | |
Max.working temperature | ℃ | 1650(oxid) | 1350 | 1600 |
Main Application Areas of Silicon Carbide :
-- functional ceramics,
-- advanced refractories,
-- abrasives
-- metallurgical materials
