Product Name：Abrasive Customized Ceramic Linings
- Product Category：
- Product Details：
Wear resistant ceramic engineered liners is specially designed abrasion resistant alumina ceramic materials. Perfectly suit for any type of application - E-Mail:
-
Abrasive Customized Ceramic Linings
More special custom ceramic linings shapes availalbe ,Engineered linings product is a speciality of chemshun.
Engineered linings product is a speciality of chemshun. We can supply and install a wide range of pre-engineered alumina ceramic tiles tailor-made to suit any type of application . CAD software is used to design wear resistant lining for customer’s components. Machining before sintering makes us able to provide linings with complex and 3 dimensional shapes as a cost-effective solution. Which will fit nearly any geometry , A well designed engineered lining system different from standard ceramic tile bricks will make equipment with special angle without gap, so it avoid materials wastage and machines wear damage .
Chemshun Pre-engineered Advantages :
- Tailor Made engineered ceramics available
- Accept OEM & ODM wear engineered ceramics projects
- Provide professional industrial wear consult and solution
- Keep designed alumina ceramics part perfectly for equipment
Chemical Composition:
| Al2O3 | SiO2 | CaO | MgO | Na2O |
| 92~93% | 3~6% | 1~1.6% | 0.2~0.8% | 0.1% |
Physical Properties:
| Specific gravity (g/cc) | >3.60 |
| Apparent porosity (%) | 0 |
| Flexural Strength (20℃, Mpa) | 280 |
| Compressive strength (20℃, Mpa) | 850 |
| Rockwell hardness (HRA) | 80 |
| Vickers hardness (hv) | 1050 |
| Moh’s hardness (scale) | ≥9 |
| Thermal Expansion (20-800℃, x10-6/℃) | 8 |
| Crystal Size (μm) | 1.3~3.0 |
Product Technical Data （1：wear resistant ceramic)
You may want to know :
How to test the Mohs hardness of wear resistant ceramics
